Motion detector 160° 2-wire technology suitable for LED
Description
Motion detector 160° 2-wire technology suitable for LED
This comfortable motion directly replace an ON / OFF switch ( not suitable for AC circuit ! ) Starts as 1 Watt - ideal for LED !
Technical specifications:
This comfortable motion directly replace an ON / OFF switch ( not suitable for AC circuit ! ) Starts as 1 Watt - ideal for LED !
Technical specifications:
- on-off switch PIR
- Twilight threshold adjustable
- Switching time 10 sec. - 7 min
- Detection angle 160 °
- Range max . 9m
- Mounting dimensions WxHxD 49x49x30mm
- suitable for flush-mounted boxes and cavity wall boxes Ø60mm Ø68mm
- An appliqué 80x80mm
- Installation height 100-180cm
- Power range 1-500W for resistive loads such as incandescent lamps ,
- 1-200W for inductive loads such as LED lamps or fluorescent tubes
- 230V ~ / 50Hz
- Power consumption standby 0.1W , operating 0,45W
- IP20 , only for inside
