LED Moving Head with a 15W RGB LED

LED Moving Head with a 15W RGB LED - LED TMH-6

Item number: TEAD-35-120100V

The powerful!

Category: Power supplies - second live

Price on application

Currently unavailable or sold out!

LED Moving Head with a 15W RGB LED - LED TMH-6

Equipped with a 15 W tricolor LED with RGB colors
Through the close chip placement of the multichip technology, an exquisite color mix even with short distances to the illuminated surface is provided
Compact lightweight
13 or 5 DMX channels selectable for numerous applications
Positioning within 540° PAN and 270° TILT
Stepless RGB color changing
Color-macro-function for an easy selection of possible color-combinations
Gobo-wheel with 9 static gobos plus open
With gobo-shake function
Rainbow-effect with adjustable speed
Programmable color-change speed and strobe effect
Strobe effect with 1-10 flashes per second
Exact positioning via 16 bit PAN/TILT movement resolution
PAN-angle switchable between 540°, 360° and 180° (in sound and auto mode)
TILT-angle switchable between 270°, 180° and 90° (in sound and auto mode)
DMX-controlled operation or stand-alone operation with Master/Slave function
8 motion macros can be called up via DMX controller
Sound-controlled via built-in microphone
Addressing via control panel with 4-digit LED display
DMX control via every standard DMX controller

Technical specifications:

Power supply:	230 V AC, 50 Hz ~
Power consumption:	60 W
DMX control channels:	13/5
DMX512 connection:	3-pin XLR
Flash-rate:	10 Hz
Sound-control:	via built-in microphone
LED type:	15 W TCL
Number of LEDs:	1
Beam angle:	11°
Static gobo-wheel:	9 gobos and open
Maximum PAN-movement:	540°
Maximum TILT-movement:	270°
Dimensions (LxWxH):	170 x 175 x 245 mm
Weight:	3.8 kg
Color:	Black
Shipping weight:	3.70 kg
Ecodesign regulation:	Yes
Special product:	Not designed for household room illumination
Purpose:	Show effect lighting
