2SC2240 NPN 120V 100mA 300mW TO220

Item number: 2SC2240

Category: 2SC...

0,20 €

including 19% VAT. , plus shipping (Standard)

In stock!

Shipping time: 2 - 5 workdays

piece

Description

2SC2240 NPN 120V 100mA 300mW TO220
    Material of Transistor: Si
    Polarity: NPN
    Maximum Collector Power Dissipation (Pc): 0.3 W
    Maximum Collector-Base Voltage |Vcb|: 120 V
    Maximum Collector-Emitter Voltage |Vce|: 120 V
    Maximum Emitter-Base Voltage |Veb|: 5 V
    Maximum Collector Current |Ic max|: 0.1 A
    Max. Operating Junction Temperature (Tj): 150 °C
    Transition Frequency (ft): 50 MHz
    Collector Capacitance (Cc): 3 pF
    Forward Current Transfer Ratio (hFE), MIN: 200
    Noise Figure, dB: -
    Package: TO92
