Terminal strip for PCB assembly 8 poles

Item number: 99KL4008

2,15 €

including 19% VAT. , (Standard)

From piece	Price per unit
3	2,09 €

In stock!

Shipping time: 2 - 5 workdays

Terminal strip for PCB assembly 8 poles

Manufacturer

Type of connector	PCB terminal block
Spatial orientation	angled 90°
Contacts pitch	5.08mm
Number of ways	8
Mechanical mounting	on PCBs
Electrical mounting	cage clamp, screw terminal, THT
Connector	terminal
Contact plating	tinned
Current rating	10A
Height	10mm
Colour	green
Rated voltage	300V
Body material	polyamide
Connectors features	assembling possibility
Length	50mm
Depth	8mm
Flammability rating
Type of pin configuration	1x8
Conform to the norm
Wire size	26AWG...16AWG
Wire cross section	0.25...1.5mm²

Traces of storage possible.
