Professional 5 channel club mixer - CM-5300

Item number: 6010006950

Category: Mixers


549,00 €

including 19% VAT. , (Standard)

From piece Price per unit
2 532,53 €
Available

Shipping time: 2 - 5 workdays

piece


Description

Professional 5 channel club mixer - CM-5300

  • High-grade stereo mixer for clubs and numerous mobile PA applications
  • 5 stereo input channels with gain control, 3-band kill EQ (+12/ -26dB) and 10-digit LED level meter
  • Front panel aux input
  • Rear stereo input FOH for stage mixers
  • Smooth dual-rail channel input faders (60 mm/100 mm)
  • 3 microphone input channels with front combo connector
  • Gain control, peak LED, 3-band EQ and ?on air? switch per microphone channel
  • One-knob compressor per microphone channel
  • 2-parameter adjustable auto talkover for automatic music level reduction when microphone is used
  • Fully assignable smooth dual-rail crossfader (45 mm)
  • Master section with two separately controllable stereo outputs, output 2 switchable to mono
  • 10-digit stereo LED level meter, switchable between both master outputs
  • Balanced XLR and unbalanced main outputs
  • Additional mono zone output (with switchable 80Hz HPF) which can be routed to the master bus or channel 5
  • 10-digit LED level meter for the zone output
  • Mono subwoofer output with integrated active crossover (frequency/level adjustable)
  • All outputs with rear-side maximum level setting controls
  • Adjustable effects send/return path, assignable to mic or master bus
  • PFL section with PFL/Main mix control and cue mix/split option
  • Record output, independent of the master
  • Rack installation, 7 U

Technical specifications:

Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 25 W
Inputs:
MIC 1-3: combination XLR/6.3 mm jack bal.
LINE 1-5: RCA L/R
PHONO 1,2: RCA L/R
AUX: 3.5 mm stereo jack
FOH: 6.3 mm jack bal.
FX SEND: 6.3 mm jack unbal.
Ausgänge:
MAIN 1,2: XLR L/R bal., RCA L/R
ZONE: XLR bal.
SUB: XLR bal.
REC: RCA L/R
FX SEND: 6.3 mm jack unbal.
PHONES: 6.3 mm jack unbal.
Frequency range: 20-20 000 kHz
Distortion: 0.05 % (line)
S/N ratio: >82 dB (line)
Dimensions (LxWxH): 383 x 483 x 106 mm (19", 7 U)
Weight: 4.7 kg
Shipping weight: 8.00 kg
