Potentiometer axial stereo 10K lin - VRB-100S10
Description
Potentiometer axial stereo 10K lin - VRB-100S10
with slotted 6mm shaft, for 18-tooth push-on knobs, with nut mounting and print-board lugs.
Specifications
with slotted 6mm shaft, for 18-tooth push-on knobs, with nut mounting and print-board lugs.
Specifications
- resistance 2 x 10 kO
- Char.lin.
- load capacity 0.1 W
- Insulation resistance < 100 MOhm / 500 VDC
- Preload 500 V~ / 1 min.
- Synchronization ± 3 dB, 0 / -40 dB
- rotation angle 300 ° ± 5 °
- detent no
