Potentiometer axial mono 10K log - VRB-141M100W
Description
Potentiometer axial mono 10K log - VRB-141M100W
With slotted 6mm shaft, for 18-tooth push-on knobs, with nut fastening and printed circuit board solder terminals.
With slotted 6mm shaft, for 18-tooth push-on knobs, with nut fastening and printed circuit board solder terminals.
- Resistance 100K
- Char.log.
- Load capacity 0.1W
- Insulation resistance < 100MOhm / 500VCD
- Test voltage 500 V?/1 min.
- Synchronism ±3 dB, 0/-40 dB
- Rotation angle 300° ± 5°
- Detent 41
- Axle length 7mm
- Print connection angled
