Mono PA mixing amplifier with integrated CD/MP3 player and radio - PA 3120/RCD
Description
Mono PA mixing amplifier with integrated CD/MP3 player and radio - PA 3120/RCD
- 1 x 120 WRMS
- CD player with drawer mechanism, repeat function and random play, reproduction of audio CD/CD-R/CD-RW, MP3 CD, USB interface, separate on/off switch
- AM/FM radio module with 5 programmable station buttons, scan buttons, volume control and separate on/off switch
- 4 mic/line inputs, to be configured via DIP switches (mic/line, phase, high-pass filter, 48 V phantom power)
- 2 aux inputs, to be configured via DIP switches (aux1/aux2, 10 dB attenuation, high-pass filter)
- Siren function and chime function
- Priority circuit
- Speaker outputs via screw terminals
- Line output
- Insert facility for preamplifier
- Input and output level controls
- 2-way tone control for the output
- 482 mm (19") rack installation
Technical specifications
Output power: 120 WRMS
Mic input: 1.8 mV
Aux input: 300 mV
Phono input: -
Speaker output: 4/8/16 O, 70/100 V
Frequency range: 50-16,500 Hz, ±3 dB
Equalizer bass: ±10 dB/100 Hz
Equalizer midrange: -
Equalizer treble:±10 dB/10 kHz
S/N ratio: > 65 dB
THD: 0.5 % (1 W)
Power supply: 230 V?/50 Hz/365 VA
Admiss. ambient temp.: 0-40 °C
Dimensions: 483x110x450 mm, 2 RS
Weight: 10.5 kg
Special feature: USB
Inputs
Microphone: mic/line:
4 x XLR/6.3 mm (combo)
4 x plug-in screw terminal
Aux, phono
2 x RCA L/R (aux 1/2)
2 x plug-in screw terminal
