Mixing amplifier with MP3 player + Bluetooth 2 x 50 watts - EPA-100BT
Description
Mixing amplifier with MP3 player + Bluetooth 2 x 50 watts - EPA-100BT
The 1 U flat stereo mixing amplifier EPA-100BT with efficient class D output circuitry is particularly suitable for permanent installations in restaurants, gyms and retail locations which require quick-access music playback control.
It provides 2 x 50 watts at 4 ohms and lets you play and control music from multiple sources. Equipped with connections for a microphone and a line-level audio source, it also features a built-in audio player with USB port and memory card slot as well as a Bluetooth receiver for wireless audio streaming directly from your smartphone, tablet or any other Bluetooth-enabled device.
Features
The 1 U flat stereo mixing amplifier EPA-100BT with efficient class D output circuitry is particularly suitable for permanent installations in restaurants, gyms and retail locations which require quick-access music playback control.
It provides 2 x 50 watts at 4 ohms and lets you play and control music from multiple sources. Equipped with connections for a microphone and a line-level audio source, it also features a built-in audio player with USB port and memory card slot as well as a Bluetooth receiver for wireless audio streaming directly from your smartphone, tablet or any other Bluetooth-enabled device.
Features
- 1 U flat stereo mixing amplifier with 2 x 50 watts power
- For quick-access music playback control in restaurants, fitness studios and retail locations
- Built-in audio player with USB port and SD card slot
- Blue backlit LCD screen
- Integrated Bluetooth audio streaming
- Adjustable stereo line input via XLR and RCA jacks
- Adjustable microphone input on the front panel
- Controls for volume, bass and treble
- Signal, clip and power indicators
- Stereo line output via XLR and RCA jacks
- Screw terminals for low-impedance speakers
- Groundlift switch against humming
- Limiter for overload protection
- Efficient class D circuitry
- Low weight and height due to integrated switch mode power supply
- Rack installation, 1 U
- Housing design: (19") 48.3 cm rack installation built-in 1 U
Technical specifications:
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 100 W |
| output: | 30 W RMS (8 ohms) |
| 50 W RMS (4 ohms) | |
| Power connection: | Mains input IEC connector (M) mounting version via Power supply cord with safety plug (provided) |
| Frequency range: | 20 - 20000 Hz |
| Cooling fan: | Yes |
| Connections: | 2 x 2-pole clamp |
| Audio player: | USB + SD + Bluetooth |
| Mode of operation: | Class D |
| Range: | 10 m Bluetooth |
| Carrier frequency: | 2,4 GHz |
| Housing design: | (19") 48.3 cm rack installation built-in 1 U |
| Width: | 48,3 cm |
| Height: | 4,45 cm |
| Depth: | 21 cm |
| Weight: | 2,59 kg |
| Inputs: | |
| Line: | RCA and XLR, balanced |
| Mic: | combination XLR/6.3 mm jack, balanced |
| Outputs: | |
| Line: | RCA and XLR, balanced |
| Circuitry: | class D |
| Audio player: | |
| Playback format: | MP3, WMA, WAV |
| Available storage media: | USB devices and SD(HC) cards up to 32 GB |
